METRIC
MIL-DTL-24441/40B(SH)
27 August 2009
SUPERSEDING
MIL-DTL-24441/40A(SH)
19 May 1999
DETAIL SPECIFICATION SHEET
PAINT, EPOXY-POLYAMIDE, RED, FORMULA 162, TYPE IV
This specification is approved for use by the Naval Sea Systems Command, Department of the Navy, and is
available for use by all Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and
MIL-DTL-24441.
FORMULA: This formula covers red epoxy-polyamide paint designated Navy Formula 162, Type IV for
interior or exterior use. The paint shall consist of the ingredients specified in the quantities specified.
Component A11/
Ingredients
Kilograms
Pounds
Thixatrope1/
---
---
Polyamide2/
13.61
30.0
Polyamide adduct3/
214.55
473.0
Silica4/
46.27
102.0
Mineral spirits5/
49.90
110.0
Butyl alcohol6/
47.17
104.0
Component B11/
Ingredients
Kilograms
Pounds
Thixatrope7/
---
---
Epoxy resin8/
321.6
709.0
Silica4/
28.12
62.00
Red iron oxide9/
57.15
126.0
Naphtha10/
66.68
147.0
See footnotes on next page.
AMSC N/A
FSC 8010
