MIL-DTL-53039E
be of synthetic origin and not naturally occurring. The titanium dioxide shall be a rutile, chalk
resistant type conforming to ASTM D476, type III or IV. If other tinting pigments are used to
match the spectral characteristics, these additional pigments shall have good color stability.
When tested in accordance with 4.6, no component of the coating shall contain lead, cadmium,
cadmium compounds, and hexavalent chromium. Compounds of antimony, arsenic, beryllium,
cyanide, manganese, mercury, nickel and selenium shall be absent. The flattening pigment
materials shall be of polymeric based polyurethane or urea formaldehyde condensation type
polymers or other polymeric composition. The amount shall not exceed the limits of table VIII.
Glass beads for Interior Aircraft Black, 37031 shall conform to TT-B-1325, type I, grade B and
shall conform to the amount specified in table VIII.
3.4.1.1 Lead content. The lead content shall not exceed 0.05 percent by weight of total
nonvolatile content upon analysis as specified in 4.6.6.
3.4.2 Nonvolatile vehicle. The nonvolatile vehicle shall be a hydroxyl terminated prepolymer
reacted with an aliphatic polyisocyanate. The IR spectrum of the partially cured resin shall show
the presence of aliphatic polyisocyanates and shall contain no aromatic polyisocyanates when
determined as stated in 4.6.7.
3.4.3 VOC content. The VOC content for the types of coatings shall be as specified in 1.2.1 and
tested in accordance with 4.6.8.
3.4.4 VOHAP content. All types of coatings, except for type VIII aerosols, shall be VOHAP-
free when tested in accordance with 4.6.8.1.
TABLE VI. Pigmentation.
Color
Pigment
Acid insoluble green pigment predominately
Dark Green, 34082
composed of cobalt, zinc and chromium oxides with
Green 383, 34094
other oxides permitted; carbazole dioxazine violet,
IRR Foliage Green 504, 34160
iron oxides, light stable organic yellow and orange,
zinc/magnesium ferrite or other mixed metal oxides.
Complex inorganic acid insoluble green pigment
Green 808, 34102
(Non-Cobalt), chromium oxide, titanium dioxide,
light stable organic yellow or orange, carbazole
dioxazine violet, iron oxides, zinc/magnesium ferrite
or other mixed oxides.
Field Drab, 33105
Chromium oxide, titanium dioxide, carbon black,
Brown 383, 30051
carbazole dioxazine violet, iron oxides,
Earth Yellow, 33245
zinc/magnesium ferrite or other mixed metal oxides.
Sand, 33303
Tan 686A, 33446
Tan, 33531
Woodland Desert Sage, 34201
Dark Sandstone, 33510
9
