MIL-PRF-24647E
TABLE IV. Identification characteristics 1/.
Applicable ASTM
Criteria
test method
Biocide (record manufacturing range or variation, ±%, method used to determine) 2/ 6/
---
Volatiles (record manufacturing range or variation, ±%) 3/
ASTM D2369
Nonvolatile vehicle (record manufacturing range or variation, ±%)
ASTM D2697
Consistency, gram equivalent KU (record manufacturing range or variation, ±KU)
ASTM D562
Weight per unit volume (record manufacturing range or variation, ±g/L)
ASTM D1475
Dry-to-touch time [record maximum not to exceed 2 hours at 20 °C (68 °F), at
ASTM D5895
ASTM F718 film thickness]
Dry-hard time [record maximum not to exceed 16 hours at 20 °C (68 °F), at
ASTM D5895
ASTM F718 film thickness]
Flash point [record required minimum not less than 21 °C (70 °F)]
ASTM D3278
Pot life (where applicable) (record hours, temperatures)
---
Color
R0 1.8 4/
---
All other paint system colors
ASTM D1729
Infrared spectra of nonvolatile vehicle
ASTM D2621
Sag resistance (record minimum value)
ASTM D4400
Toxicity 5/
---
Copper leach rate (Types II and IV only) 2/ 6/
ASTM D6442
Ablation/erosion rate (Types I and II only) 2/ 6/
ASTM D4938,
ASTM D4939, or as
approved by
NAVSEA
1/
Copper content (Types II and IV only) 2/
NOTES:
1/
Manufacturing range percentages having variations of more than ±3%, without supporting documentation,
will be rejected and can cause delay or rejection of qualification. When specified (see 6.2), manufacturers
will provide documentation for any identification characteristics deemed non-applicable (i.e., drytime for a
tie-coat designed to be overcoated before completely drying). Also, should a test method not be applicable
for the product, the manufacturer will record the data and the alternative test method used.
2/
Antifouling topcoats only.
3/
VOC shall be determined in accordance with 4.4.3.
4/
Determine in accordance with 4.4.8.
5/
Certify in accordance with 3.3.5.2.
6/
Value as determined by manufacturer.
3.4 Qualitative requirements. See table IV for required tests.
3.4.1 Color. Colors of the individual paints of the paint systems shall:
a. Be as reported by vendor as an identification characteristic for that paint, when tested in accordance with
4.4.8.1, for the colors of the individual anticorrosive and tie-coat paints, except R0 color paints.
9
