MIL-DTL-11414F

TABLE IV. Test method index � Continued

Test

Requirement

ASTM

Test

Paragraph

Method

Hydrocarbon resistance

4.5.22

3.6.9

Adhesion

4.5.23

3.6.10

D3359

Salt spray resistance

4.5.24

3.6.11

B117

Weather resistance

4.5.25

3.6.12

Reactivity

4.5.26

3.6.13

Corrosion

4.5.27

3.6.14

Onset of

4.5.28

3.6.15

decomposition

4.5.2 Test procedures. Tests shall be conducted in accordance with table IV. The right is reserved to

make any additional tests deemed necessary to determine that the coating meets the requirements of

this specification.

4.5.3 Test panels. Unless otherwise specified, metal panels used for test purposes shall be

two types:

a. Steel, cold rolled, pretreated with zinc phosphate coating B-952 with P60 chrome

rinse, 0.032 inches (0.8128 mm) thick, for all tests except flexibility.

b. Steel, tinplated, 0.010 inches (0.254 mm) thick, for flexibility only.

4.5.4 Color. Determine the color in accordance with ASTM D1729 by applying films with a

0.002 inch (0.004 inch gap clearance) film applicator on a black and white hiding chart until

complete hiding is obtained. Evaluate for compliance with 3.3.

4.5.5 Pigment analysis. Extract the pigment as in ASTM D2371, except use ethanol for the

extraction. Make appropriate qualitative and quantitative tests on the extracted pigment to

determine if only permissible pigments were used. Nonconformance to 3.4.1 shall constitute

failure of this test.

4.5.5.1 Antimony, arsenic, beryllium, cadmium, cyanide, manganese, mercury, nickel and

selenium. Manufacturers need to review applicable environmental and safety regulations and

comply with material shipment requirements (see 6.2). The MSDS needs to include a notarized

statement that verifies that the composition of the material (coating formulation) is free of the

antimony, arsenic, beryllium, cadmium, cyanide, manganese, mercury, nickel, selenium and their

compounds.

4.5.6 Extender pigment. Determine siliceous matter and barium sulfate by the applicable

portions of ASTM D5380. Evaluate for compliance with table I.
