gal\) maximum] volatile organic content \(VOC\) complying paint. The paint is a special-purpose white alkyd enamel \(Formula Number 30\) for interior use, either primed steel or primed aluminum \(see 6.1\). This product may be used wherever VOC air pollution regulations apply. Product is supplied in a single can and used as supplied without thinning.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13

MIL-DTL-1115E

TABLE VI. Hazardous solvent content.

Hazardous solvent in total enamel

Maximum, %WT

Benzene

0.05

Chlorinated solvent(s), total

0.05

Carbon tetrachloride

Chloroform (trichloromethane)

Methylene chloride (dichloromethane)

Tetrachloroethylene (perchloroethylene)

1,1,1-Trichloroethylane (methyl chloroform)

Trichloroethylene

Ethyl benzene

0.05

Methyl, ethyl and butyl mono-ethers of

0.05

ethylene glycol or the acetates, total

(methyl, ethyl and butyl cellosolves

and acetates)

Methyl ethyl ketone (MEK)

0.05

Methyl isobutyl ketone (MIBK)

0.05

Toluene

0.05

Xylene (all forms), total

0.1

3.4 Qualitative requirements. The enamel shall conform to the qualitative requirements specified in 3.4.1

through 3.4.11.

3.4.1 Odor. The odor shall be characteristic of the volatiles permitted when tested as specified (see table VII).

3.4.2 Color. The color of the enamel shall match the dry color chip no. 17875 of FED-STD-595 when tested as

specified (see 4.5.12). The measured color deviation term, ΔE, from color number 17875 of MIL-STD-595 in

Commission Internationale de l'Eclairage (CIE; International Commission on Illumination) LAB units shall not be

greater than 1.0 CEILAB unit.

3.4.3 Flexibility. The enamel shall show no evidence of cracking when tested as specified (see 4.5.7).

3.4.4 VOC regulations. Thinning of this VOC compliant paint is not allowed. This paint is to be used as

supplied without thinning (see 4.5.4).

3.4.5 Condition in container. When tested as specified in 4.5.8, a freshly opened, full container of enamel shall

be free from lumps, abnormal thickening, or livering and shall show no more pigment settling or caking than can be

readily reincorporated to a smooth, uniform state.

3.4.5.1 Storage stability.

3.4.5.1.1 Full container. When tested as specified in 4.5.9.1, the product shall be capable of being readily

broken up with a paddle to a smooth uniform consistency. It shall be free from livering, curdling, gelling, pigment

float, hard caking, gummy sediment, or other objectionable properties for at least 1 year after date of manufacture.

The enamel shall conform in all respects to this specification.

3.4.5.1.2 Partially full container. When tested as specified in 4.5.9.2, the enamel shall show no skinning at the

end of 48 hours. In addition, the enamel shall show no livering, curdling, hard caking, or gummy sediment after

being in a partially filled container at 26�C (80 �F). The enamel shall mix readily to a smooth uniform state. Any

skin formed shall be easily removed.
